| Use | Doors for use externally in houses and apartments |
| Thermal transmittance | U=0,91 W/m2K panel doors / U=1,20 W/m2K glass doors |
| Door type | Outside opening (for Danish market - DK model inwards opening) |
| Sound transmittance | 31 dB |
| Door thickness | 62 mm |
| Decoration | White painted S0502-Y, S0500-N gloss 25, 1 layer - impregnation, 2 layers - priming, 1 layer - painting |
| Frame, profile | Single step profile: 42x105, 42x115, 42x105NOR, 42x115NOR |
| Bottom section-threshold | Hardwood impregnated 26x105, 26x115 |
| Standard accessories | Lock: ASSA565. Hinges:3248 - 2 pcs. Seal: S3417. Lock pate: 0034 ZN |
| Glass lists | PVC plastic glass list |
| Glass | Transparent single chamber glass packet (double glass - 12mm) |
| Non-standart size production | Available for all models at non-standard |
| Decoration according NC and RAL | Available for all models at non-standard |
| Other glazing options | Not available |
| Other lock case and hinges | Available for all models at non-standard |
| Product quality warranty | 7 years, factory guarantee |
| Product quality warranty | 10 years, door blade form |
| Marking | CE / European |
|
1. HDF panels surface, 3mm |
|
2. Aluminum panels |
|
3. Finger joined pine wood frame |
|
4. Glass package, 2 glasses |
|
5. PVC plastic glass lists |
|
6. Polystyrene core |
|
7. Rubber seals |
|
8. Frames, profiles 42x105,42x115,42x105NOR,42x115NOR |
|
9. Threshold, hardwood, 26x105, 26x115 |
|
10. Door thickness 62mm |
U=0,91 W/m2K | U=1,20 W/m2K
Non-standard Line
|
Min/Max size
|
Min width
|
Max width
|
Min Height
|
Max Height
|
|
mm
|
160
|
925
|
160 | 2040 |
|
M size
|
2.35
|
10
|
2.35 | 21 |
*The minimum and maximum dimensions of the door leaf is specified for one leaf door. If you want to order a double door, each of the door leaf must not exceed the allowable dimensions.
